Dymax BlueWave® LED Flood-Curing System

The BlueWave LED Flood-Curing System offers high-intensity curing energy over a 5″ x 5″ (12.7 cm x 12.7 cm) area. Cure times in the 5-30 second range are typical when using Dymax light-curable materials. The unit is simple to operate and can be used as a stand-alone system or easily integrated into automated assembly systems.
The BlueWave Flood-Curing System is available in three different irradiator wavelength array configurations (365, 385, and 405 nm). This enables users to fully optimize the curing process between their light-curable material and UV curing chamber. Get all the benefits of LED light-curing technology including more consistent intensity, less energy consumption, a shutter-free design, instant on/off, and cooler curing temperatures. Standard systems include one array, a power supply, and appropriate power and interface cords. Optional accessories such as shields and stands are available and sold separately.
FEATURES:
Larger curing area: 5″ x 5″ (12.7 cm x 12.7 cm)
High-intensity LED: (850 mW/cm2 typical at 385 nm) & (950 mW/cm2 typical at 405 nm)
Greener technology
Instant on/off
Shutter-free design
LED flood array available in 365, 385, and 405 nm wavelength options
Self-contained, lightweight LED flood array with cable interface and PLC port
Full line of accessories available
