ELPEGUARD® Twin-Cure® DSL 1600 E-FLZ thick film coatings

PRODUCT DESCRIPTION
FEATURES of ELPEGUARD® Twin-Cure® DSL 1600 E-FLZ thick film coatings
APPLICATIONS of ELPEGUARD® Twin-Cure® DSL 1600 E-FLZ thick film coatings
About Vật tư Sunflower
PRODUCT DESCRIPTION
The ELPEGUARD® thick film coatings of the series Twin-Cure® DSL 1600 E-FLZ are used to protect and insulate electronic assemblies so that they can fulfill higher requirements regarding reliability and service life. Owing to their very good resistance against moisture and condensation excellent protection against corrosion (such as electro-corrosion and migration) is possible even under harsh climatic conditions.
FEATURES of ELPEGUARD® Twin-Cure® DSL 1600 E-FLZ thick film coatings
basis: copolymerize of polyurethane (UR) and polyacrylate (AR)
solvent-free / VOC-free
powerful protection through electrical insulation properties directly after UV curing
chemical cross-linking reaction in shadow zones
excellent mechanical and chemical resistance
tested according to IPC-CC-830B and MIL-I-46058C
UL-approval according to UL 94 (UL file No. E80315): best flame class V-0
UL-approval of DSL 1600 E-FLZ/75 according to UL 746E (UL file No. E80315)
temperature range of -65 to +130 °C [-85 to 266 °F] the lower the viscosity, the higher the elasticity, and the easier material tension can be
lowered even under rapid and extreme thermal shocks
depending on the coating thickness also suitable for coating flexible circuits (“flex-to install”, bending stress during assembly only)
excellent edge coverage, wetting and underfilling of components (“micro-casting”), very
good capillary-active behavior, yet not suitable as underfill material
excellent adhesion
halogen-free according to JPCA-ES01-2003 and IEC 61249-2-21
high transparency and yellowing resistance
DSL 1600 E/500 is especially suitable for lighting electronics
when applied in thick layers, components may be fixed to protect against vibration
can be mechanically stripped for repair purposes (blasting method).
APPLICATIONS of
ELPEGUARD® Twin-Cure® DSL 1600 E-FLZ thick film coatings
Electronics
Automotive
Lighting electronics
