High Conductivity TPG* Thermal Leveler

Momentive Performance Materials Inc. offers a unique high crystalline graphite known as Thermal Pyrolytic Graphite (TPG), which exhibits 4x higher thermal conductivity than copper but with ¼ of copper’s weight. TPG is manufactured from thermal decomposition of hydrocarbon gas at an extremely high temperature. The high alignment of the graphene layers gives the product superior thermal conductivity which makes it an excellent thermal management material for:
– Thermal leveler
– Wafer susceptor
– Thermal strap
– Heat sink fin
FEATURES:
Highly oriented crystals in a layered structure
In-plane conductivity (1,500~1,700 W/m-K)
Fully dense ceramic (2.25 gm/cm3)
Thickness 0.010″ (0.25mm) ~ 0.600″ (15mm)
Typical size up to 4″ (100mm) x 12″ (300mm)
Can be joined for larger geometries
Resilient layered structure
Easily machined, provided as plates or as final shapes
Compatible with many encapsulating techniques
APPLICATIONS:
Semiconductor wafer processing
Microelectronic packaging
Finned heat sinks
